Camera

• Image Sensor: 2 MP CMOS
• Max. Resolution:1920 (H) × 1080 (V)
• Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
• Shutter : Time PAL: 1/25 s to 1/50,000 s; NTSC: 1/30 s to 1/50,000 s
• Day & Night: 24/7 Color Imaging
• Angle Adjustment: Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°
• Slow Shutter: Max. 16 times

Lens

• Lens Type:                        3.6 mm, 6 mm fixed focal lens
• Focal Length & FOV:   3.6 mm, horizontal FOV: 83.0°, vertical FOV: 44.4°, diagonal FOV: 98.0°

                                                 6 mm, horizontal FOV: 51.0°, vertical FOV: 28.5°, diagonal FOV: 58.7°

• Lens Mount:                    M16

Illuminator

• Supplement Light Type:      White Light
• Supplement Light Range:   Up to 40 m
• Smart Supplement Light:   Yes


• Image Parameters Switch: STD/HIGH-SAT
• Image Settings: Brightness; Sharpness; Mirror; AGC
• Frame Rate :     PAL: 1080p@25fps

NTSC: 1080p@30fps

• Wide Dynamic Range (WDR):≥130 dB
• Image Enhancement: BLC;HLC
• Privacy Mask:4 programmable privacy masks
• Noise Reduction:3D DNR
• White Balance:  Auto/Manual

Interface

• Video Output: Switchable TVI/AHD/CVI/CVBS;1 HD analog output

Event

• Motion Detection: 4 programmable motion areas

General

• Power:12 VDC ± 25%, max. 4.2 W

                *You are recommended to use one power adapter to supply the power for one camera.

• Material: Front cover Metal, Main body: Plastic
• Dimension: 223.1 mm × 77.1 mm × 82.6 mm (8.78″ × 3.04″ × 3.25″)
• Weight: Approx. 436 g (0.96 lb.)
• Operating Condition: -40 °C to 60 °C (-40 °F to 140 °F), humidity: 90% or less (non-condensation)
• Communication: HIKVISION-C
• Language: English

Approval

• Protection: IP67
